Specification

Country of Origin: Material: Thickness: Density : Color : Fire :

Germany Nylon 6 , Polyester facing 10mm 825 g/m2 Black mesh with grey facing GB8627-2007

Installation

1. Check the floor smoothness，Clean the floor, cut the perimeter isolation strip into the appropriate size (Model: NOISESTOP® PEF3200),
in general the height should be 20mm higher than the floor finish. Then, apply the glue at the back of
isolation strip and adhere through wall.　　

2．Place Enkasonic over subfloor (or waterproofing membrane if applicable) with the black mesh down, white
fabric side up. Tape sufficiently to prevent movement of the Enkasonic strips during construction

3. After the Enkasonic is installed, place one layer of GRC board on top of the matting. Then, place a second layer of GRC board.　　

4．Install tongue and groove wood-floor on top of the floating 2-layer GRC board. Trim the excess PEF3200
perimeter isolation board. Apply sealant at the edge.

Illustration

Accessories

Environmental Requirement

Download

Enkasonic E Catalogue
